Ultra Isolation Transformer

Get a Price/Quote

Product Details:

Rated Voltage 415 Volt (V)
Product Type Isolation Transformer
Material Mild Steel
Frequency (MHz) 50 Hertz (HZ)
Usage Industrial
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Ultra Isolation Transformer Price And Quantity

Minimum Order Quantity 1 Piece

Ultra Isolation Transformer Product Specifications

Frequency (MHz) 50 Hertz (HZ)
Usage Industrial
Material Mild Steel
Product Type Isolation Transformer
Rated Voltage 415 Volt (V)

Ultra Isolation Transformer Trade Information

Supply Ability 10 Piece Per Week
Delivery Time 5 Days

Product Description

Ultra Isolation Transformer

Our company offer heavy duty Ultra Isolation Transformer that can be used in low to high powered electrical systems. The primary and secondary coils of this machine are provided with insulation to keep them truly isolated from each other. It is capable to operate up to the voltage of 415 volts with an input frequency of 50 to 60 Hertz. It is provided with safety units that gives excellent protection from surges, spikes, and transients. Ultra Isolation Transformer availed by our company has a coil ratio of 1:1. Get this high performance machine at a reasonable price range.

Technical Specification

Ratio: 415 V / 415 V 3ph or 240 /240V 1ph. Nominal
Acceptable Input Range: +/-10%
Mode of operation : 1:1
Isolation Transformer Frequency: 47 to 63 Hz.
Common mode noise rejection: Over 100 dB
Coupling Capacitances:0.012 PF
DC Galvanic Isolation: Over 500 Megohms between any winding or windings to ground
Breakdown strength: 2500 VAC for 2 minutes
Load Regulation: Within 3 to 5 %
Termination: On Terminal Plate
